Suction parameters
Steel type: length 6-12m, width 1.8-2.8m, plate thickness 4-250mm, weight of single piece not exceeding 16 tons.
Steel plate thickness(mm) |
Number of sheets |
4 |
6 |
6 |
4 |
8-10 |
3 |
12-20 |
2 |
More than 20 |
Leaflet |
B. Billet: Billet size is about 150X150mm, length is 9-12m, and each weight is about 2 tons. It is required to suck and hang a single layer at a time.
C. Lifting weight: It is required that the total weight of the suspended cargo does not exceed 20 tons.
D, the suction temperature: steel temperature is less than 100 °C.
